GEAR2000 - User Manual - Chronology of publications:
First edition September 2000
Second edition February 2003
Third edition February 2004
Fourth edition April 2005
Fifth edition January 2007
Sixth edition March 2008
Seventh edition July 2009
Eighth edition February 2012
Ninth edition September 2013
Tenth edition June 2014
Eleventh edition July 2015
Twelfth edition March 2017
Thirteenth edition December 2019
Fourteenth edition January 2022
|
New Tutorial Video
|
GEAR2000 is an application oriented to the analysis and optimization of
the gear pair, connected
with working conditions complying with DIN 58400-58405-3960-867, CETEHOR, ANSI/AGMA
2005-D03.
Main functionality
? Negative allowance check, sliding analysis and balancing with/without change in distance
between centers; advise for the optimized solution.
? Mesh graphic simulation and clearance check.
? Recalculation and check of all input-parameters, looking for DIN specification; every
inconsistency is displayed, sanction is required to standard dispensation.
? Tooth profile and whole gear generation, output of CAD file in DXF and Mi format.
? Solid generation for mesh 3D graphic simulation; 3D output in Iges3D,STEP, STL and
VRML format.
? Plotting and printing of complete gear data, complying DIN standard.
? Whole gear profile generation, ready to use on NC Machine (EDM Wire).
? Storing and loading design data, modify and redesign capability.
Benefits
? Minimum input of parameters: omitted parameters are recalculated in compliance with
standard DIN.
? Interactive modification using WIZARD and DIALOG-BOX facilities.
? Short elaboration time.
? The designer can choose between the proposed and optimized solution.
? Functional test of immediate graphic and alphanumeric outputs reduces error
? possibility
GEAR2000 is
interfaced with other CAM SOFT s.r.l. applications oriented to the working
on
CN machine like:
· EDM2000 EDM wire profile cutting for dies.
· PGL2000 2.5 axes milling and turning.
CAM SOFT s.r.l. does not provide any warranty in respect of the present
material.
This manual is sold as is,without warranty of any kind, either express or implicit, respecting the
contents of this manual, including but not limited to implied warranties for the manual’s quality,
performance, merchantability, or fitness for any particular purpose.
CAM SOFT s.r.l. shall not be liable to the purchase or any other
person or entity with respect to
any liability, loss or damage caused or alleged to be caused directly or indirectly by this manual.
CAM SOFT s.r.l. declines every responsability derived from errors
contained in this manual, or
for damages (accidental or not) derived from the supply, interpretation an use of this manual.
GEAR2000 Help
